LATHE CD61180 1800 X 10000MM
* Large lathe with 1800mm swing over bed
* Full one piece cast bed with high 1100mm bed width for rigid turning under all conditions
* Has a capacity of 18ton between centres
* Headstock has a three bearing spindle support and is fitted with Japanese Koyo-P5 precision bearings offering smooth running under all turning conditions
* Fitted with hydraulic braking for quick stopping of workpiece
Accessories Included – 4 Jaw chuck, Steady, Coolant system.
SKU: 100-1346
Nil Stock ETA: Please Enquire
LATHE CD61180 1800 X 10000MM
Price per Unit(piece):
Original price was: .$0.00Current price is: $0.00. (Exc GST)
Original price was: .$0.00Current price is: $0.00. (Inc GST)
- FEATURES
- SPECIFICATIONS
FEATURES
* Large lathe with 1800mm swing over bed
* Full one piece cast bed with high 1100mm bed width for rigid turning under all conditions
* Has a capacity of 18ton between centres
* Headstock has a three bearing spindle support and is fitted with Japanese Koyo-P5 precision bearings offering smooth running under all turning conditions
* Fitted with hydraulic braking for quick stopping of workpiece
Accessories Included – 4 Jaw chuck, Steady, Coolant system.
SPECIFICATIONS
| ETA: | please enquire |
| Speed Range (rpm): | 3-136 |
| Tool Height (mm): | 50 |
| Tailstock Taper: | MT7 |
| Threading Imperial (tpi): | BSP 46, 28-1 Tooth/Inch |
| Threading Metric (mm): | 46, 1-244mm |
| Spindle Taper: | Metric 140 |
| Spindle Bore (mm): | 100 |
| Speeds (no.): | 16 |
| Model No.: | CD61180 |
| Spindle Nose: | A2-20 |
| Bed Width (mm): | 1100 |
| Distance Between Centres (mm): | 10,000 |
| Swing Over Gap (mm): | No Gap |
| Swing Over X-Slide (mm): | 1450 |
| Swing Over Bed (mm): | 1800 |
| Motor Power (kW): | 30kw |
| Coolant System: | False |
